APPLICATIONS

• Chemicals - paints, solvents, intermediaries, resin, polymers and other acidic and basic chemicals
• Pharmaceuticals
• Petrochemicals
• Suitable for various process industries for clean/clear liquids without any suspended particles

SPECIFICATIONS

• Delivery size up to 100 mm
• Capacity up to 300 m3/hr
• Head up to 150 metres
• Speed 2900, 1450, 980 rpm at 50 Hz and 3500, 1750, 1150 rpm at 60 Hz.
• Temperature from (-)50° to 180° C

FEATURES

• Seal-less and glandless pump
• Magnetic drive pump comprises permanent magnet
• Zero leakage
• Designed as per ISO 2858/DIN EN 22858/ISO 5199 standards

MATERIAL OF CONSTRUCTION (MOC)

• Pump casting, casing cover, wear ring and impeller shaft made of stainless steel and tested as per ASTM A351 M – CF8M
• Pump shaft made of stainless steel and tested as per ASTM A276, Type 316 and 316L
• Other (MOC) options available such as ASTM A890/890M CD4MCuN-1B Duplex, Alloy ASTM B473 UNS8020, ASTM A494 – Hastelloy B
